PD1019 SERIES SERVICE BRAKE

The Carlisle Brake & Friction PD1019 Series Service Brake is a hydraulically actuated, single piston, fixed caliper disc brake designed for a variety of dynamic braking requirements. The single actuated piston requires the disc to float axially. This brake provides low torque ranges for light to moderate service conditions. Multiple caliper usage on the same disc is not recommended.

Additional Product Details

Flexible mounting alternatives to accommodate numerous equipment types
Constructed from aluminum casting for light weight
Equipped with Carlisle premium asbestos-free linings, providing superior stopping performance and life
Optional seal materials available for compatibility with all actuation fluids and temperatures

Technical Specifications

Caliper Material	Aluminum
Disc Diameter Range	8 in (203.2 mm) to unlimited
Disc Thickness	0.25 in / 6.35 mm
Displacement per Brake	.1 in³ (.65 cm³)
Inlet Type	.125-27 NPTF
Lining Area per Brake	3.53 in² / 22.77 cm²
Maximum Pressure	300 psi / 20.68 bar
Mounting Attitude	3, 12 o’clock
Number of Pistons	1
Assembly Weight	2 lbs / 0.91 kg
